12 Bar 17 Bar Differential Pressure Switch For Water 15A

12 Bar 17 Bar Differential Pressure Switch For Water 15A
12 Bar 17 Bar Differential Pressure Switch For Water 15A 12 Bar 17 Bar Differential Pressure Switch For Water 15A 12 Bar 17 Bar Differential Pressure Switch For Water 15A 12 Bar 17 Bar Differential Pressure Switch For Water 15A

Large Image :  12 Bar 17 Bar Differential Pressure Switch For Water 15A

Product Details:
Place of Origin: China
Brand Name: Keram Controls
Certification: CE
Model Number: QYD waterproof
Payment & Shipping Terms:
Minimum Order Quantity: 50 pcs
Price: USD25-50/piece EXW factory
Packaging Details: Carton
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union
Supply Ability: 5000 pcs per month

12 Bar 17 Bar Differential Pressure Switch For Water 15A

Description
Name: Differential Pressure Switches Certification: CE
Warranty: 1 Year Customized Support: OEM
Max. Current: 15A Max. Voltage: 250V
Max. Working Pressure: 30 Bar Temperature: -40 ~+85℃
High Light:

Keram Controls 17 Bar differential pressure switch for water

,

Keram Controls differential pressure switch for water

,

15A differential pressure flow switch

12 Bar 17 Bar Differential Pressure Switch For Water 15A



Description



QYD Waterproof Differential Pressure Switch



Waterproof Adjustable Differential Pressure Switches for Air Conditioning



QYD series differential pressure controls is designed to prove flow through pumps Renovated SPDT micro-switch ensure the reliable  swith function Used in fluorinated refrigerant,but also in air and liquid(-20 to 120°C)

Flexible mounting bracket suits various kinds of application.

Various connections are available on request.

IP65 rating

CE approval


Specifications

Model Differential (bar) Factory setting (bar) Max working pressure(bar)
Min Max
QYD2C(W) 0.5 2 0.5 12
QYD4C(W) 0.5 3.5 1 12
QYD4CH(W) 0.5 3.5 1 30
QYD6CH(W) 1 6 6 30
QYD4C/B(W) 0.3 4 0.3 17

Dimensions



12 Bar 17 Bar Differential Pressure Switch For Water 15A 0






Installations (Electrical Wiring, Connections)



12 Bar 17 Bar Differential Pressure Switch For Water 15A 1



Operating Instruction



1. The new outer cover,two fifingers pinch both sides of the plastic lid,open the outer cover can be pumped out;

2. To be installed in the pipe,must use two wrenches and twist tight;

3. Do not install the controller over electric rating of the device.



12 Bar 17 Bar Differential Pressure Switch For Water 15A 2



FAQ



1 Q: What's the delivery time?

A: According to the specification and quantity of your order, generally 4

days for normal standard products within 10pcs.



2 Q:Are you manufacturer or trading company?

A: We are manufacturer with many years of experience.We have our

own factory.Welcome to visit our factory.



3 Q: Can we use our logo on the products?

A: Yes.We can provide OEM service.



4 Q: Do you have products with ex-proof certificate?

A: Yes,we can offer intrinsic-safety and flame proof certificates.



5 Q: What is the warranty of your products?

A: Normal is 12 months.



6 Q: What's the means of transport?

A: Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
