Product Details:
|
| Name: | Liquid Differential Pressure Transmitter | Customized: | OEM |
|---|---|---|---|
| Measurement Unit: | Mbar | Certification: | CE |
| Accuracy: | <0.25% FS | Response: | 1s |
| Media: | Air, Oil, Water | Operating Temp: | -20 To 80℃ |
| Storage Temp: | -40 To 80℃ | Tolerated Overpressure: | X15 |
| Power Supply: | 24Vac/dc | Output: | 4-20mA 0-10V |
| Housing Metrial: | Brass, SS | Protection: | IP65 |
| High Light: | 2 Wire Liquid Differential Pressure Switch,BSP liquid differential pressure switch,Keram Controls sensor pressure transmitter |
||
Liquid Differential Pressure Transmitter 1/8 BSP 2 wire Output IP65
The KLDP series differential pressure transmitter use a piezo-resistive sensor and incorporate zero and span adjustment.
They are ideal for use in areas requiring exact pressure measurement, 0.25% high accuracy, low hysteresis and long term stability.
For all applications where air, oil or water are to be monitored.
KLDP series pressure transmitters are suitable for measuring pressure in all applications
where air, oil or water are to be monitored. Also compatible with refrigerants. They are
suitable for all kind of tasks in air-conditioning, heating and water systems.
| Model | KLDP |
| Measurement units | mbar |
| Accuracy | <±0..25%FS |
| Response time | 1s |
| Repeatability | ±0.1% at FS/year |
| Media | Air, oil or water |
| Operating temperature | -20 to +80℃ |
| Storage temperature | -40 to +80°C |
| Tolerated over pressure | x15 |
| Power Supply | 24Vac/dc |
| output signal | 4-20mA(2wires) |
| 0-5/0-10VDC (3 wires) | |
| Housing material | Brass/Stainless steel |
| Protection class | I65/NEMA4 |
KLDP-Ranges-Output-House material
| Model | Range | Output | House Material | |||
| KLDP | 0 to 35 mbar | (1) | 4-20mA(2 wires) | (E) | Brass | (B) |
| 0 to 70 mbar | (2) | 0-5/0-10VDC (3 wires) | (F) | Stainless Steel | (C) | |
| 0to 350 mbar | (3) | |||||
| 0 to 1 bar | (4) | |||||
| 0 to 2 bar | (5) | |||||
| 0 to 7 bar | (6) | |||||
| o to 17 bar | (7) | |||||
KLDP-3-E-B
| Model | KLDP differential pressure transmitter |
| Ranges | 0 to 350 mbar |
| Output | 4-20mA(2 wire) |
| House material | Brass |
1 Q: What's the delivery time?
A: According to the specification and quantity of your order, generally 4
days for normal standard products within 10pcs.
2 Q:Are you manufacturer or trading company?
A: We are manufacturer with many years of experience.We have our
own factory.Welcome to visit our factory.
3 Q: Can we use our logo on the products?
A: Yes.We can provide OEM service.
4 Q: Do you have products with ex-proof certificate?
A: Yes,we can offer intrinsic-safety and flame proof certificates.
5 Q: What is the warranty of your products?
A: Normal is 12 months.
6 Q: What's the means of transport?
A: Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
