0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms

0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms
0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms
0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms

Large Image :  0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms

Product Details:
Place of Origin: China
Brand Name: KeramControls
Certification: CE
Model Number: KDP110
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: $69-$51/pic
Packaging Details: Carton
Delivery Time: 7-10days
Payment Terms: T/T, L/C
Supply Ability: 2000pic/month

0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms

Description
Measurement Units: Pa Output Signal: 0~10V
Housing Material: PC&ABS,UL94V-0
High Light:

IP65 Differential Pressure Sensor

,

200pa Differential Pressure Sensor

,

Pharmaceutical Rooms DPT Differential Pressure Transmitter

0-±200pa IP65 house protection filter differential pressure sensor for Pharmaceutical clean rooms



Description

KDP110 series differential pressure transmitter is a relatively cheap price, but the function is simple, the measurement range can only be adjusted by the DIP switch, and there is no display, which can meet the customer's requirements for the price, but at the same time we guarantee the quality and accuracy .


Feature



  • Ranges from -25/+25Pa to -10000/+10000Pa (according to models)
  • Auto zero manual calibration
  • Voltage, current, digital signal output
  • Standard accuracy <±1% FS
  • IP65 house protection

Application



  • HVAC system
  • Pharmaceutical clean rooms
  • Electronic clean rooms
  • Medical clean rooms
  • Commercial buildings
  • Public transport hub

Technical data



Model KDP110
Measurement Units Pa,mmH2O,mmHG,mbar
Accuracy <±1% FS@-5 to +65℃
Response Time 0.5s
Repeat Stability ±0.01 % at FS /Year
Resolution 0.1 Pa; 0.1 mmH2O; 0.01mbar; 0.01mmHG
Media Air and neutral gases
Operating Temperature -20…+70℃
Storage Temperature -40…+60℃
Power Consumption <1.5W
Tolerated over pressure x15
Power Supply 16~30VAC/DC (3wire) / 18~30VDC (2wire)
Output Signal 4-20mA(2wire)
4-20mA(3wire)
0~5V/0~10VDC(3wire)
RS-485
Customized
Auto Zero Manual calibration
Housing Material PC&ABS,UL94V-0
Protection Class IP65/NEMA4
Cable Gland M16*1.5

Dimension



0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 00-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 1


Measuring range adjustment



0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 2


Output setting(3 wire Model)



0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 3

0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 4


Manual Zero-point correction



0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 5


Ordering guide



KDP110-Range-Output



Model Range Output
KDP110 -100~+100Pa (1) 4-20mA(2 wire) (E)
-1000~+1000Pa (2) 4-20mA(3 wire) (F)
-2000~+2000Pa (3) 0-5/0-10V(3 wire) (G)
-10000~+10000Pa (4) RS-485 (H)
    Customized



0-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 60-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 70-±200pa IP65 House Protection Filter Differential Pressure Sensor For Pharmaceutical Clean Rooms 8



FAQ

1 Q: What's the delivery time?

A: According to the specification and quantity of your order, generally 4

days for normal standard products within 10pcs.



2 Q:Are you manufacturer or trading company?

A: We are manufacturer with many years of experience.We have our

own factory.Welcome to visit our factory.



3 Q: Can we use our logo on the products?

A: Yes.We can provide OEM service.



4 Q: Do you have products with ex-proof certificate?

A: Yes,we can offer intrinsic-safety and flame proof certificates.



5 Q: What is the warranty of your products?

A: Normal is 12 months.



6 Q: What's the means of transport?

A: Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
