IP65 30 Bar Differential Pressure Switches Waterproof

IP65 30 Bar Differential Pressure Switches Waterproof
IP65 30 Bar Differential Pressure Switches Waterproof IP65 30 Bar Differential Pressure Switches Waterproof IP65 30 Bar Differential Pressure Switches Waterproof IP65 30 Bar Differential Pressure Switches Waterproof

Large Image :  IP65 30 Bar Differential Pressure Switches Waterproof

Product Details:
Place of Origin: China
Brand Name: Keram Controls
Certification: CE
Model Number: QYD waterproof
Payment & Shipping Terms:
Minimum Order Quantity: 50 pcs
Price: USD25-50/piece EXW factory
Packaging Details: Carton
Delivery Time: 3-5 working days
Payment Terms: T/T, Western Union
Supply Ability: 5000 pcs per month

IP65 30 Bar Differential Pressure Switches Waterproof

Description
Name: Differential Pressure Switches Certification: CE
Warranty: 1 Year Customized Support: OEM
Max. Current: 15A Max. Voltage: 250V
Max. Working Pressure: 30 Bar Temperature: -40 ~+85℃
High Light:

30 Bar Differential Pressure Switches

,

IP65 Differential Pressure Switches

,

Waterproof diff pressure switch

IP65 30 Bar Differential Pressure Switches Waterproof



Description



QYD Waterproof Differential Pressure Switch.

IP65 Waterproof Adjustable Differential Pressure Switches for Air Conditioning.



QYD series differential pressure controls is designed to prove flow through pumps Renovated SPDT micro-switch ensure the reliable  swith function Used in fluorinated refrigerant,but also in air and liquid(-20 to 120°C).

IP65 rating

CE approval

Flexible mounting bracket suits various kinds of application.

Various connections are available on request.


Specifications

Model Differential (bar) Factory setting (bar) Max working pressure(bar)
Min Max
QYD2C(W) 0.5 2 0.5 12
QYD4C(W) 0.5 3.5 1 12
QYD4CH(W) 0.5 3.5 1 30
QYD6CH(W) 1 6 6 30
QYD4C/B(W) 0.3 4 0.3 17

Dimensions



IP65 30 Bar Differential Pressure Switches Waterproof 0






Installations (Electrical Wiring, Connections)



IP65 30 Bar Differential Pressure Switches Waterproof 1



Operating Instruction



1. The new outer cover,two fifingers pinch both sides of the plastic lid,open the outer cover can be pumped out;

2. To be installed in the pipe,must use two wrenches and twist tight;

3. Do not install the controller over electric rating of the device.



IP65 30 Bar Differential Pressure Switches Waterproof 2



FAQ



1 Q: What's the delivery time?

A: According to the specification and quantity of your order, generally 4

days for normal standard products within 10pcs.



2 Q:Are you manufacturer or trading company?

A: We are manufacturer with many years of experience.We have our

own factory.Welcome to visit our factory.



3 Q: Can we use our logo on the products?

A: Yes.We can provide OEM service.



4 Q: Do you have products with ex-proof certificate?

A: Yes,we can offer intrinsic-safety and flame proof certificates.



5 Q: What is the warranty of your products?

A: Normal is 12 months.



6 Q: What's the means of transport?

A: Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
