Product Details:
|
| Measurement Range: | -35...+80℃ | Temperature Range: | DIP Switch |
|---|---|---|---|
| Protection Class: | IP65/NEMA4 | Accuracy: | ±0.3℃(20-60℃) |
| Highlight: | NEMA4 Temperature And Humidity Transmitter,30m/s Temperature And Humidity Transmitter,IP65 HVAC Temperature Humidity Transmitter |
||
KTH510 series temperature and humidity transmitter has passed the official CE certification of the European Union. It is a temperature and humidity transmitter that meets market requirements and has a humanized design. , is a product that can reassure customers. Its design concept is high precision, stable operation, beautiful appearance, convenient and fast installation, and favorable price. It is a temperature and humidity transmitter that is really suitable for consumers.
More convenient wiring and setting
Cable size φ5…12mm
Prevent the pollution of the shell surface in harsh environment
| Model | KTH510 |
| Power Supply | 16-30VDC(2wire 4-20mA)/16-30V AC or V DC (0-5V/0-10V/4-20mA/RS-485 ) |
| Output | 4-20mA/0-5V/0-10V/RS-485 |
| Operating Temperature | -30…+70℃ |
| Storage Temperature | -40…+60℃ |
| Operating Humidity | 0...100%RH |
| Temperature Range | DIP Switch |
| Maximum Wind/Flow Speed | 30m/s |
| Electromagnetic compliance | EN61326-1,Industrial Environment |
| Housing Material | PC&ABS,UL94V-0 |
| Protection Class | IP65/NEMA 4 |
| Cable Gland | M16*1.5 |
| Measurement Performance-Temperature | |
| Measurement Range | -35...+80℃ |
| Accuracy | ±0.3℃(20-60℃) |
| Temperature Dependence | ±0.01℃/℃ |
| Measurement Performance-Humidity | |
| Measurement Range | 0...100%RH |
| Accuracy | ±2%(0-90% @25℃)/±3%(90-100%@25℃) |
| Stability in Typical HVAC Applications | ±0.01RH/Year |
KTH510——Output——Installation——Filter
| Model | Output | Installation | Filter | |||
| KTH510 | 4-20mA(2 wire) | (E) | Wall | (W) | PTFE | (P) |
| 4-20mA(3 wire) | (F) | Duct | (D) | Stainless | (S) | |
| 0-5V/0-10VAD(3 wire) | (G) | |||||
| RS-485 | (H) | |||||
