0-±500pa White Differential Pressure Sensor For HVAC Pressure Control

0-±500pa White Differential Pressure Sensor For HVAC Pressure Control
0-±500pa White Differential Pressure Sensor For HVAC Pressure Control
0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 0-±500pa White Differential Pressure Sensor For HVAC Pressure Control

Large Image :  0-±500pa White Differential Pressure Sensor For HVAC Pressure Control

Product Details:
Place of Origin: China
Brand Name: KeramControls
Certification: CE
Model Number: KDP210
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: $69-$51/pic
Packaging Details: Carton
Delivery Time: 7-10days
Payment Terms: T/T, L/C
Supply Ability: 2000pic/month

0-±500pa White Differential Pressure Sensor For HVAC Pressure Control

Description
Media: Air And Neutral Gases Auto Zero: Manual Calibration
Protection Class: IP65/NEMA 4
High Light:

500pa White Differential Pressure Sensor

,

IP65 HVAC Pressure Control Transmitter

,

NEMA4 Differential Pressure Sensor



0-±500pa factory price white Differential Pressure Sensor for HVAC pressure control



Description



The KDP210 differential pressure transmitter series has multiple ranges to choose from, from as low as ±25pa to as high as ±10000pa, to meet the different needs of customers. At the same time, it has the characteristics of high precision, high temperature resistance, waterproof and dustproof, making it suitable for comparison Harsh environments, such as: high temperature and humidity, severe weather such as rain and snow, or harsh environments such as wet dust.


Feature



  • Ranges from -25/+25Pa to -10000/+10000Pa (according to models)
  • Auto zero manual calibration
  • Voltage, current, digital signal output
  • Standard accuracy <±1% FS
  • IP65 house protection

Application



  • HVAC system
  • Pharmaceutical clean rooms
  • Electronic clean rooms
  • Medical clean rooms
  • Commercial buildings
  • Public transport hub

Technical data



Model KDP210
Measurement Units Pa,mmH2O,inWG,mmHG,KPa,mbar
Accuracy <±1% FS@-5 to +65℃
Response Time 0.5s
Repeat Stability ±0.01 % at FS /Year
Resolution 0.1 Pa; 0.1 mmH2O; 0.01mbar; 0.01mmHG
Media Air and neutral gases
Operating Temperature -20…+70℃
Storage Temperature -40…+60℃
Power Consumption <1.5W
Tolerated over pressure x15
Power Supply 16~30VAC/DC (3wire) / 18~30VDC (2wire)
Output Signal 4-20mA(2wire)
4-20mA(3wire)
0~5V/0~10VDC(3wire)
RS-485
Customized
Auto Zero Manual calibration
Housing Material PC&ABS,UL94V-0
Protection Class IP65/NEMA4
Display Backlight LCD display
Cable Gland M16*1.5

Dimension(mm)



0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 0

0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 1


Measuring range adjustment



0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 2


Output setting(3 wire Model)



0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 3

0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 4


Manual Zero-point correction



0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 5


Ordering guide



KDP210-Range-display-output



Model Ranges Display output
KDP210 -100~+100Pa (1) LCD backlight (D) 4-20mA(2 wire) (E)
-1000~+1000Pa (2)     4-20mA(3 wire) (F)
-2000~+2000Pa (3)     0-5/0-10VDC (3 wire) (G)
-10000~+10000Pa (4)     RS-485 (H)
        Customized



0-±500pa White Differential Pressure Sensor For HVAC Pressure Control 60-±500pa White Differential Pressure Sensor For HVAC Pressure Control 70-±500pa White Differential Pressure Sensor For HVAC Pressure Control 8



FAQ

1 Q: What's the delivery time?

A: According to the specification and quantity of your order, generally 4

days for normal standard products within 10pcs.



2 Q:Are you manufacturer or trading company?

A: We are manufacturer with many years of experience.We have our

own factory.Welcome to visit our factory.



3 Q: Can we use our logo on the products?

A: Yes.We can provide OEM service.



4 Q: Do you have products with ex-proof certificate?

A: Yes,we can offer intrinsic-safety and flame proof certificates.



5 Q: What is the warranty of your products?

A: Normal is 12 months.



6 Q: What's the means of transport?

A: Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
