M16 Air Velocity Transmitter For Intelligent Building Control

M16 Air Velocity Transmitter For Intelligent Building Control
M16 Air Velocity Transmitter For Intelligent Building Control
M16 Air Velocity Transmitter For Intelligent Building Control M16 Air Velocity Transmitter For Intelligent Building Control M16 Air Velocity Transmitter For Intelligent Building Control M16 Air Velocity Transmitter For Intelligent Building Control M16 Air Velocity Transmitter For Intelligent Building Control

Large Image :  M16 Air Velocity Transmitter For Intelligent Building Control

Product Details:
Place of Origin: China
Brand Name: KeramControls
Certification: CE
Model Number: KAV120
Payment & Shipping Terms:
Minimum Order Quantity: 10 pcs
Packaging Details: Carton
Delivery Time: 7 days
Payment Terms: L/C, T/T

M16 Air Velocity Transmitter For Intelligent Building Control

Description
Electromagnetic Compatibility: EN61326-1 Standard (industrial Environment) Measuring Range: 1~30m/s
Output: 4-20mA/ 0-5V/ 0-10V/ RS-485
High Light:

M16 Air Velocity Transmitter

,

30m/s Air Velocity Transmitter

,

EN61326-1 Velocity Transmitter

M16 air velocity transmitter for intelligent building control



Description



KAV120 series wind speed transmitter has a sensitive response to very low wind speeds, close to accurate measurement of 0m/s air velocity. When the sensor is powered by 16VDC/VAC~24VDC/VAC, the output is 0-5V/0-10V/4-20mA/RS-485 signal, and the output and the wind speed have a fixed linear relationship, and the repeatability and consistency of the sensor output are very good high. Using the integral hot film anemometer, the anti-vibration capability is much higher than that of the traditional hot wire anemometer. With a variety of installation methods, the probe can be easily fixed in the measured airflow position.


Specification



Model KAV120
Power supply 16-24VAC or VDC
output 4-20mA/ 0-5V/ 0-10V/ RS-485
Operating temperature -5…+70℃
Storage temperature -20…+70℃
Permissible humidity 0…90 %RH
Measuring range 1~30m/s
Accuracy 0.2%FS
Working frequency 50Hz
Maximum air velocity 30m/s
Electromagnetic compatibility EN61326-1 standard (industrial environment)
Housing material ABS
Protection IP65/ NEMA4
Cable gland M16*1.5

Dimensions



M16 Air Velocity Transmitter For Intelligent Building Control 0


Ordering Guide



Model-Output-Display-Range-Probe



Model Output Display Range Probe
KAV120 4-20mA(3 wire) (F) YES (D) 0…1 m/s (1) RVVR0.5mm2 70
0-10V(3 wire) (G) No (-) 0…2m/s (2) RVVR1mm2 200
Rs-485 (H)     0…5 m/s (3) RVVR1.5mm2 300
0-5V(3 wire) (J)     0…10 m/s (4)
        0…15 m/s (5)
        0…20 m/s (6)
        0…30m/s (7)



M16 Air Velocity Transmitter For Intelligent Building Control 1





FAQ



1 Q: What's the delivery time?

A: According to the specification and quantity of your order, generally 4

days for normal standard products within 10pcs.



2 Q:Are you manufacturer or trading company?

A: We are manufacturer with many years of experience.We have our

own factory.Welcome to visit our factory.



3 Q: Can we use our logo on the products?

A: Yes.We can provide OEM service.



4 Q: Do you have products with ex-proof certificate?

A: Yes,we can offer intrinsic-safety and flame proof certificates.



5 Q: What is the warranty of your products?

A: Normal is 12 months.



6 Q: What's the means of transport?

A: Express such as TNT,Fedex,DHL,UPS, or logistics by indicator.
